TP-Link Archer C24 / AC750

Tp-link Archer C24 AC750 Dual-Band Wi-Fi Router https://www.tp-link.com/au/home-networking/wifi-router/archer-c24/ Standards Wi-Fi 5 IEEE 802.11ac/n/a 5 GHz IEEE 802.11n/b/g 2.4 GHz WiFi Speeds AC750 5 GHz: 433 Mbps (802.11ac) 2.4 GHz: 300 Mbps (802.11n) WiFi Range 2 Bedroom Houses 4× Fixed Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas WiFi Capacity Medium Dual-Band Allocate devices to different bands for optimal performance Working Modes Router Mode Access Point Mode Range Extender Mode HARDWARE Processor Single-Core CPU Ethernet Ports 1× 10/100 Mbps WAN Port 4× 10/100 Mbps LAN Ports Buttons WPS/Reset Button Power 9 V ⎓ 0.6 A SECURITY WiFi Encryption WEP WPA WPA2 WPA/WPA2-Enterprise (802.1x) Network Security SPI Firewall Access Control IP & MAC Binding Application Layer Gateway Guest Network 1× 5 GHz Guest Network 1× 2.4 GHz Guest Network SOFTWARE Protocols IPv4 IPv6 Parental Controls URL Filtering Time Controls WAN Types Dynamic IP Static IP PPPoE PPTP L2TP Quality of Service QoS by Device NAT Forwarding Port Forwarding Port Triggering DMZ UPnP IPTV IGMP Proxy IGMP Snooping Bridge Tag VLAN DHCP Address Reservation DHCP Client List Server DDNS NO-IP DynDNS Management Tether App Webpage Check Web Emulator> PHYSICAL Dimensions (W×D×H) 4.5 × 4.2 × 1.0 in (115 × 106.7 × 24.3 mm) Package Contents Wi-Fi Router Archer C24 Power Adapter RJ45 Ethernet Cable Quick Installation Guide OTHER System Requirements Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser Cable or DSL Modem (if needed) Subscription with an internet service provider (for internet access) Certifications FCC, CE, RoHS Environment Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~60℃ (-40℉ ~140℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing TEST DATA WiFi Transmission Power CE: <20dBm(2.4GHz) <23dBm(5GHz) WiFi Reception Sensitivity 5GHz: 11a 54M: -76dBm; 11ac VHT20 MCS8: -71dBm; 11ac VHT40 MCS9: -66dBm; 11ac VHT80 MCS9: -62dBm 2.4GHz: 11g 54M: -76dBm; 11n HT20 MCS7: -73dBm; 11n HT40 MCS7: -71dBm
